Precision Engineering: High-Performance Ceiling T-Grid Production Lines

The PROMAX Ceiling T-Grid Machine is an industry-leading, fully automated manufacturing system specifically designed for the high-speed production of Main Tees, Cross Tees, and Wall Angles. As the structural backbone of modern suspended ceiling systems, T-Grid components require surgical precision to ensure a perfect "click-lock" fit. Our machinery is engineered to meet these exacting standards, delivering the durability and aesthetic finish required for commercial and industrial interior design.

Advanced Integrated Manufacturing Process

A PROMAX production line is a masterpiece of synchronized automation, ensuring a seamless transition from raw coil to finished product. The integrated system includes:

• Automatic Decoiler & Leveling: Handles galvanized steel or prepainted aluminum coils with precision, ensuring the material is stress-free and perfectly flat before forming.

• Intelligent Punching & Notching: Features high-speed hydraulic units that create the sophisticated fire-expansion slots and interlocking end-tabs (hooks) essential for a secure, tool-free grid assembly.

• Precision Roll Forming Mill: Utilizing vacuum-heat-treated rollers made from high-grade GCr15 or Cr12 alloy steel, our mill maintains the delicate geometry of T15 and T24 systems while protecting the decorative surface of the material.

• High-Accuracy Cutting System: A hydraulic "flying-cut" shear provides burr-free edges and exact lengths at production speeds up to 30–50 meters per minute.

Smart Controls & High-Efficiency Output

Equipped with a world-class PLC control system (Siemens/Mitsubishi) and a user-friendly touchscreen interface, the PROMAX T-Grid machine allows for rapid adjustments and minimal material waste. Whether you are producing standard flat T-grids, silhouette profiles, or black line groove grids, our equipment ensures high consistency and structural integrity.

Why Choose PROMAX?

In the competitive ceiling market, efficiency is everything. PROMAX machines are built for 24/7 industrial operation, featuring reinforced frames and low-maintenance designs. By investing in our Ceiling T-Bar production lines, you are choosing a high-ROI solution that guarantees the highest architectural quality, reduced labor costs, and a competitive edge in the global construction supply chain.
